THE MIAMI WORKSHOP
OSM is best known for machining in place, but some repairs are faster, cheaper, or simply better done off the engine. Our Miami machine shop is the closest full-capability reconditioning and machining facility to the Caribbean cruise corridor, so components can be turned around during the same port call.
We recondition engine and rotating-equipment components to OEM specification on heavy lathes, horizontal boring mills, and a vertical mill, from cylinder liners and heads to connecting rods, counterweights, centrifugal pumps, and hydraulic cylinders.
Every component leaves with a certified dimensional report to OEM tolerance, accepted by DNV, Lloyd's Register, ABS, Bureau Veritas, NK, and RINA. When a job is better done in place, the same specialists deploy onsite, one team, both delivery models.
Workshop Profile
Location
Miami, FL · 6500 NW 35th Ave
Turnaround
Same-city, port-call
Standard
OEM specification
Reporting
Certified dimensional reports
Serves
Miami · Port Everglades · Port Canaveral
Reports accepted
DNV · LR · ABS · BV · NK · RINA
WHAT WE RECONDITION
COMPONENTS, IN-HOUSE
From a single cylinder head to a full set of running gear, reconditioned to OEM tolerance and returned ready to fit.
Cylinder Liners
Bore and seat work, counter-bore cutting, landing-ring and flange-face resurfacing.
Cylinder Heads
Fire-face resurfacing, valve-seat pocket machining and insert fitting, injector-bore and stud-hole repair.
Connecting Rods
Big-end and small-end bore re-machining and alignment on the horizontal boring mill.
Counterweights
Bolt-on counterweight landing and seating faces machined flat, true, and to torque.
Piston Crowns
Ring-groove and sealing-land dimensional restoration and crown clean-up.
Main Bearing Housings
Bore line-boring and alignment correction, bearing-cap seating-face machining.
Centrifugal Pumps
Shaft, impeller, wear-ring and casing-face machining and reconditioning.
Hydraulic Cylinders
Cylinder-bore and ram / rod turning, end-cap and gland-face restoration.
Pump & Gear Shafts
Journal turning, keyway cutting, coupling and pilot-diameter restoration.
Coupling & Flange Parts
Flange-face milling, hub-bore machining, bolt-hole and keyway correction.
Don't see your component? Send us the drawing — if it fits the machines, we can recondition it.
WORKSHOP EQUIPMENT
MACHINES & CAPACITY
Knuth Sinus D 400/1500 Lathe
800mm swing · 1,500mm between centers
Shaft journals & bearing surfaces
Nardini AM32240 Lathe
1,092mm swing · 6,096mm between centers
Cylinder liners, shafts & hydraulic cylinders
Metalmaq 3VKH Vertical Mill
X 862 · Y 432 · Z 483mm
Seating surfaces & keyways
Nomura 100b Horizontal Boring Mill
Y 1,270 · X 1,422 · W 1,524mm · 4,990kg table
Engine blocks, bearing housings & connecting rods
Nomura 85b Horizontal Boring Mill
Y 1,016 · X 1,016 · Z 813mm · 3,600kg table
Rotary-table cylinder-head operations
SEND US YOUR COMPONENT
Calling Miami, Port Everglades, or Port Canaveral? Tell us the component and timeline and we'll turn it around to OEM spec during your port call.
REQUEST WORKSHOP MACHINING
We respond within 2 hours. Emergency? Call +1.800.903.1509
